Superior Technology

• Made for Australian Conditions – Engineered to perform in temperatures ranging from icy winters at -15°C to scorching summers up to 52°C
• Delay Timer – turns appliance on/off within a specific time period
• Sleep Mode – operates on a two-way temperature control that modulates up and down to mimic outside ambient temperatures, ensuring a comfortable sleep
• Wi-Fi and Voice Control – allows for convenient control from anywhere with the AC Freedom App⁺ (App available from the Apple Store or Google Play, and is compatible with Google Home and Amazon Alexa)
• Powerful Airflow – to reach distances of up to 15 metres for superior air distribution
• Acoustic Damping Materials – cut outdoor unit noise by up to 3dB for whisper-quiet comfort
• End of Season Cleaning Process – dries the inside of the unit, ensuring it’s free from mould, bacteria and dust during extended periods of non-use
• Advanced Automatic Air Washing – with 99.9% cleaning rate efficiency

Rinnai Quality

• 7 year limited warranty*

Download AC Freedom App

Find out which size JX Series split system your room requires

FAQs

• How much does it cost to run a Split System? >

  Running costs depend on the unit size, energy efficiency, electricity rates and how often it’s used.

  As a rough guide:

  • 2.5–3.5 kW unit: ~$0.60–$1.00 per hour
  • 5.0–7.0 kW unit: ~$1.00–$2.00 per hour

  Inverter Split Systems adjust their output once the room reaches temperature, which helps keep running costs down.

• What size Split System do I need? >

  The right size depends on room size, ceiling height, insulation, window size and how much sun the room gets.

  As a rule of thumb:

  • Bedrooms: 2.5–3.5 kW
  • Living areas: 5.0–7.0 kW
  • Large open-plan spaces: 8.0 kW+

  An installer can confirm with a heat load calculation.

  Refer to the following guide to help determine what size JX Series you require >

• Are Split Systems energy efficient? >

  Yes. Modern split systems are among the most energy-efficient ways to heat and cool a home.

  Look for:

  • High star ratings (Cooling & Heating)
  • Inverter technology
  • Zoning by room (only heat/cool where needed)
• Can a Split System heat my home as well as cool it? >

  Yes. Reverse-cycle split systems both heat and cool and are very efficient, even in colder climates.

  They use electricity to move heat rather than create it, making them cheaper to run than many traditional heaters.

• What temperature should I set my air conditioner to? >

  For comfort and efficiency:

  • Cooling: 23–25°C
  • Heating: 18–20°C

  Every degree outside these ranges can significantly increase energy use.

• How long does a Split System last? >

  With proper installation and maintenance:

  • 10–15 years is typical

  Coastal or dusty environments may require more frequent servicing.

*For full warranty terms and conditions refer to the related warranty booklet.
**PM2.5 denotes fine Particulate Matter with a diameter of 2.5 micrometers or smaller found in the air.
***R32 refrigerant: is a highly energy-efficient, low Global Warming Potential (GWP) gas used in modern air conditioners. It offers better cooling performance while using less energy, making it ideal for eco-friendly air conditioning systems.

⁺Rinnai uses a third-party application (App) to enhance your experience of the Rinnai product. You may use the App at your sole discretion. Please note that when you download and use the App and its services, the third-party’s privacy policy and terms and conditions of service will apply. By using the Rinnai product through this App, you acknowledge and agree that: The third-party App may collect, store, and process your personal information according to its own privacy policy and App terms and conditions. Rinnai does not control and are not responsible for the content, policies, or practices of the third-party App and its services. Rinnai strongly recommends that you review the App privacy policy before using its features. The use of the third-party App is optional. For further information or clarification, please contact us at 1300 555 545 and [email protected]

NB: Reverse cycle air-conditioners are an effective solution as they provide both cooling and heating and are highly efficient. However, unlike gas heaters, their heating capacity will reduce with colder ambient temperatures, which is especially relevant for homes in colder areas. Discuss with your installer things like the local climate, the size of your house, its orientation and construction (such as glazing, doors, insulation), and your expectations, so a system with the appropriate capacity can be selected.
