Rinnai Efinity 19kW
Rinnai Efinity 19kW
Cutting-edge solution for unlimited hot water
The Rinnai Efinity Electric Continuous Flow Hot Water system is a cutting-edge solution designed to deliver unlimited hot water with exceptional energy efficiency.
Perfect for modern living, this fully electric system provides instant, continuous hot water without the need for storage tanks. Engineered for superior performance and user comfort, it’s an ideal choice for environmentally conscious households and businesses. With 3-phase power requirements, the Efinity is perfectly suited for residential apartments and commercial buildings.
Its compact, space-saving design and advanced technology make it a reliable and efficient electric continuous flow hot water solution.
Electrical Requirement: 3-Phase, 50Hz
Locate Your Nearest Store
Ideal for 1 bathroom
Precise temperature control
Never runs out of hot water
Adjustable temperature and flow rates
Touch screen display
Market leading quality
Slimline design
5 year warranty
Superior technology
- 3 Phase models at 50Hz
- Available in 14 kW, 19kW and 29kW with 50°C and 60°C max. output temperatures options
- Flow rate 2.5L/min minimum operating water flow rate
- Compliance Delivers hot water in accordance with AS 3498
- Safety Lock function designed to prevent accidental operation
- IP25 rated
- For indoor use only
Rinnai quality
- 5 year warranty for residential use
- 1 year warranty for commercial use
The product information on this website (comprising product brochures, warranty information, installation manuals, diagrams, specifications and representations) relates to current products. This information may be different for superseded products. For superseded products please contact Rinnai to confirm product information.
| Rinnai – Efinity 19kW Electric Continuous Flow Hot Water System | Unit | Model ECF19I50 | Model ECF19I60 | |
| No. Shower Outlets | Warm Climates | 1 | ||
| Cool Climates | 1 | |||
| Dimensions | H x W x D | mm | 471 x 227 x 103 | |
| Weight | kg | 4.3 | ||
| Installation | Indoor | |||
| Colour | Euro White | |||
| IP Rating | IP25 | |||
| Phases / Frequency | 3 phase / 50Hz | |||
| Water Resistivity | Ω.cm | ≥ 800 | ||
| Conductivity | μS/cm | ≤ 1250 | ||
| Water Connection | G 1/2’ Female or R 1/2’ Male | |||
| Temperature Range | °C | 30 – 50 | 30 – 60 | |
| Flow Rate | @ 28°C Temperature Rise (T) | L/min | 9.9 @ 415V | |
| @ 50°C temperature rise (T) | 5.5 @ 415V | |||
| Minimum | 2.5 | |||
| Water Pressure | Minimum | kPa | 100 | |
| Maximum | 850 | |||
| Inlet Temperature | Maximum | XC | 60 | |
