Ducted Air R32 13.0kW
Discontinued
Discreet comfort. Powerful performance.
Designed for seamless whole-home heating and cooling, the 13.0kW ducted R32 system delivers efficient inverter operation, customisable zoning, smart connectivity, and whisper-quiet comfort.
Model
12.5-13.0kWOutput
1050L/sAirflow
Highlights
- Up to 8 individual zones
- AC unit control
- 5% airflow control adjustments
- ‘Filter Clean’ reminder with adjustable frequency
- Slimline design
- Rapid temperature control with personalised favourites, programmable schedules, and a sleep timer
- Programmable controller
- Reduced operational costs
- Quiet operation
- Zoning option
&w=3840&q=75)
Specifications
Rinnai – System Model No | 07 09 11 13 15 18 | |
|---|---|---|
Nominal Capacity | 7 9 11 13 15 18 kW | |
Power Supply (To Outdoor Unit) | 220~240 – 1 – 50 V- Ph-Hz | |
Maximum Input Power | 3.4 4.6 4.6 7.0 7.0 7.0 kW | |
Maximum Input Current | 16.0 21.0 21.0 31.0 31.0 31.0 A | |
Recommended Circuit Breaker Size | 20 25 25 32 32 32 A | |
Cooling | Rated Capacity | 7.3 9.0 10.5 12.5 14 17 kW |
Capacity Range | 2.38 ~ 9.00 3.15 ~ 11.85 3.15 ~ 11.85 4.20 – 15.75 4.20 – 15.75 6.80 – 19.50 kW | |
Rated Input Power | 2.1 2.55 3.1 3.45 4.2 5.25 kW | |
Rated Input Current | 9.8 14.5 14.2 18.2 18.2 22.5 A | |
Annualised Energy Efficiency Ratio [AEER]1 | 3.4 3.5 3.4 3.6 3.3 3.2 W / W | |
Heating | Rated Capacity | 7.5 10.0 11.5 13.0 14.5 18.0 kW |
Capacity Range | 1.79 – 10.5 3.45 – 13.50 3.45 – 13.50 4.44 – 16.65 4.44 – 16.65 6.90 – 21.10 kW | |
Rated Input Power | 1.7 2.25 2.7 3.15 3.6 4.55 kW | |
Rated Input Current | 7.9 12.8 12.8 16.3 16.3 19.5 A | |
Annual Coefficient of Performance [ACOP]2 | 4.3 4.4 4.3 4.1 4.0 3.9 W / W | |
1. AEER: The Annualised Energy Efficiency Ratio (AEER) measures a cooling system’s efficiency by comparing its total cooling output to the electricity it consumes, including standby power.
2. ACOP: The Annual Coefficient of Performance (ACOP) measures a heater’s efficiency by comparing its total heating output to the electricity it consumes, including standby power.
Rinnai – System Model No | 07 09 11 13 15 18 | |
|---|---|---|
Nominal Capacity | 7 9 11 13 15 18 kW | |
Power Supply (To Outdoor Unit) | 220~240 – 1 – 50 V- Ph-Hz | |
Maximum Input Power | 3.4 4.6 4.6 7.0 7.0 7.0 kW | |
Maximum Input Current | 16.0 21.0 21.0 31.0 31.0 31.0 A | |
Recommended Circuit Breaker Size | 20 25 25 32 32 32 A | |
Cooling | Rated Capacity | 7.3 9.0 10.5 12.5 14 17 kW |
Capacity Range | 2.38 ~ 9.00 3.15 ~ 11.85 3.15 ~ 11.85 4.20 – 15.75 4.20 – 15.75 6.80 – 19.50 kW | |
Rated Input Power | 2.1 2.55 3.1 3.45 4.2 5.25 kW | |
Rated Input Current | 9.8 14.5 14.2 18.2 18.2 22.5 A | |
Annualised Energy Efficiency Ratio [AEER]1 | 3.4 3.5 3.4 3.6 3.3 3.2 W / W | |
Heating | Rated Capacity | 7.5 10.0 11.5 13.0 14.5 18.0 kW |
Capacity Range | 1.79 – 10.5 3.45 – 13.50 3.45 – 13.50 4.44 – 16.65 4.44 – 16.65 6.90 – 21.10 kW | |
Rated Input Power | 1.7 2.25 2.7 3.15 3.6 4.55 kW | |
Rated Input Current | 7.9 12.8 12.8 16.3 16.3 19.5 A | |
Annual Coefficient of Performance [ACOP]2 | 4.3 4.4 4.3 4.1 4.0 3.9 W / W | |
1. AEER: The Annualised Energy Efficiency Ratio (AEER) measures a cooling system’s efficiency by comparing its total cooling output to the electricity it consumes, including standby power.
2. ACOP: The Annual Coefficient of Performance (ACOP) measures a heater’s efficiency by comparing its total heating output to the electricity it consumes, including standby power.
Disclaimer / Footnotes
Product codes: DONSR13B1 DINLR13B1
