Rinnai PX Air Conditioner suitable for sized all rooms in your home

PX Series 2.5kW

Stay comfortable all year round.

Stay comfortable year-round with smart, efficient control from the 2.5kW PX Series Inverter Split System, delivering quiet, Wi‑Fi-enabled heating, cooling, and advanced air quality features.

Model

12-17m²Room size

2.5kW 3.5kW 5.0kW 6.0kW 7.0kW 8.0kW

Where to buyFind a stockist Contact RinnaiEnquire now

Key Features

Cleaner, Healthier Air

Integrated HEPA and Cold Catalyst filtration helps create a cleaner indoor environment by reducing airborne contaminants¹ .

Self-Cleaning Air Purity

Deep cleaning technology with 56°C sterilisation helps remove up to 99%² of bacteria and reduce dust build-up, keeping your air conditioner cleaner and your indoor air fresher.

Smart Sensing, Smarter Savings

Advanced occupancy detection optimises system performance based on room usage, helping reduce energy consumption while maintaining comfortable temperatures.

Rinnai Gold Guard - for added protection

Long-Lasting Protection

Advanced Gold Guard^*** technology helps safeguard the condenser coil from corrosion, supporting dependable operation year after year³.

Highlights

Ideal for bedrooms (12-17 m²)
Eco-friendly R32 refrigerant** with energy-saving inverter technology

Extensive range of features including Sleep Curve, 3D Airflow, ECO+ and Turbo+ and Demand Control

Up to 7 star energy efficiency rating^
ECO+ – uses AI-powered control to optimise cooling efficiency, delivering greater energy savings without compromising comfort
Demand control – demand response capability (DRED) to help reduce overall power consumption at critical peak load times (subject to availability from your energy provider)

Turbo+ – rapidly adjusts room temperature by up to 6° in just 10 minutes#
Humidity control – manage room humidity with Dry Mode for balanced comfort
Sleep curve – smart sleep mode that adjusts automatically for all-night comfort
Quiet operation – engineered for quiet operation with indoor noise level down to 1.95 dB(A)##
3D airflow – delivers even cooling to every corner of the room
Breeze away – intelligently directs airflow to reduce cold drafts while maintaining effective cooling

Rinnai TX Series Air Conditioning - up to 7 energy rating

The PX Series delivers quiet, year-round comfort with Wi-Fi control, balanced airflow, and energy-saving performance.

Specifications

Dimensions	Height x Width x Depth	201 x 813 x 289 mm
Weight	Net / Gross	8.0 / 10.7 kg
Nominal Capacity		2.6 kW
Suitable Area Coverage	Up to 2.6m Insulated Ceiling	12 – 17 m²
Cooling Star Rating	Hot / Average / Cold	7.0 / 6.0 / 6.5 Stars
Heating Star Rating	Hot / Average / Cold	4.0 / 3.5 / 3.0 Stars
Airflow Distance	Turbo / Hi / Med / Lo / Min	750 / 550 / 400 / 310 / 155 m
Sound Power Level		56.6 dB(A)

Dimensions	Height x Width x Depth	201 x 813 x 289 mm
Weight	Net / Gross	8.0 / 10.7 kg
Nominal Capacity		2.6 kW
Suitable Area Coverage	Up to 2.6m Insulated Ceiling	12 – 17 m²
Cooling Star Rating	Hot / Average / Cold	7.0 / 6.0 / 6.5 Stars
Heating Star Rating	Hot / Average / Cold	4.0 / 3.5 / 3.0 Stars
Airflow Distance	Turbo / Hi / Med / Lo / Min	750 / 550 / 400 / 310 / 155 m
Sound Power Level		56.6 dB(A)

Resources

Brochure

PX Series Air Conditioner Brochure

Download

Operation-Manual

PX Series Air Conditioner Operation Manual

Download

Installation-Manual

PX Series Air Conditioner Installation Manual

Download

Operation-Manual

PX Series Air Conditioner (Wi-Fi) Wireless Smart Kit Operation Manual

Download

Warranty

Air Conditioner Warranty Booklet

Download

FAQs

Browse helpful answers to common product questions, with guidance on what to consider when choosing the right option.

Benefits

Energy-efficient operation
Heating and cooling in one system
Quiet performance
Easy installation
Individual room control

Considerations

Best for single rooms or zones
Indoor unit is visible
Requires professional installation
Regular filter cleaning is recommended
Correct sizing is important for efficiency and comfort

Disclaimer / Footnotes

¹Tested by Intertek, Report No. 250626075GZU-007 and 250626075GZU-001, an independent third-party laboratory.
² Self-Cleaning function requires manual activation.Tested by Intertek, Report No. 250626075GZU-007 and 250626075GZU-001, an independent third-party laboratory.
³ Based on independent laboratory testing under controlled conditions. Tested by China Quality Certification Centre (CQC), Report No. 2017-CH-08009. Actual performance may vary depending on environmental conditions.

#Based on internal laboratory testing of a 3.5kW unit in Cooling Turbo+ Mode, the average indoor temperature reduced from 36.10°C to 29.93°C within 10 minutes. Actual performance may vary depending on room size, layout, ambient conditions, and user behaviour.
##Check product specifications for details.
*For full warranty terms and conditions refer to the related warranty booklet.
**R32 refrigerant: is a highly energy-efficient, low Global Warming Potential (GWP) gas used in modern air conditioners. It offers better cooling performance while using less energy, making it ideal for eco-friendly air conditioning systems.
***GoldGuard: is 14-karat gold plating to provide enhanced corrosion resistance and durability.
^Dependent on mode.

⁺Rinnai uses a third-party application (App) to enhance your experience of the Rinnai product. You may use the App at your sole discretion. Please note that when you download and use the App and its services, the third-party’s privacy policy and terms and conditions of service will apply. By using the Rinnai product through this App, you acknowledge and agree that: The third-party App may collect, store, and process your personal information according to its own privacy policy and App terms and conditions. Rinnai does not control and are not responsible for the content, policies, or practices of the third-party App and its services. Rinnai strongly recommends that you review the App privacy policy before using its features. The use of the third-party App is optional. For further information or clarification, please contact us at 1300 555 545 and [email protected].

NB: Reverse cycle air-conditioners are an effective solution as they provide both cooling and heating and are highly efficient. However, unlike gas heaters, their heating capacity will reduce with colder ambient temperatures, which is especially relevant for homes in colder areas. Discuss with your installer things like the local climate, the size of your house, its orientation and construction (such as glazing, doors, insulation), and your expectations, so a system with the appropriate capacity can be selected.

The product information on this website (comprising product brochures, warranty information, installation manuals, diagrams, specifications and representations) relates to current products. This information may be different for superseded products. For superseded products please contact Rinnai to confirm product information.

Product codes: HSNRPX25 HINRPX25M HONRPX25

PX Series 2.5kW
