Rinnai Multi Split Air Conditioners

Ducted Multi Air 7.0kW

  • Warranty 03 - 7 year Residential
  • WiFi

Comfortable temperatures across multiple rooms.

Multi Split ducted air conditioning system delivers efficient heating and cooling for up to six rooms with one outdoor unit, discreet design, quiet operation, and flexible, independent climate control.
Model
7.3-8.0kWOutput
361L/sAirflow
  • Warranty 03 - 7 year Residential
  • WiFi

Highlights

  • Up to six rooms with one outdoor unit
  • Cooling output 7.3kW and heating output up to 8.0kW
  • Indoor unit can be hidden in a ceiling
  • Quiet operation
  • Wi-Fi control enabled

  • Non-obtrusive to your architectural designs
  • Great performance
  • Timer functionality
  • DC inverter technology optimises energy usage, resulting in lower electricity costs and improved comfort
  • Compatible with Rinnai Wired Controller (CNTRLDRCINW2) , sold separately

Rinnai Multi Split system - control up to 6 rooms with the one unit

Designed for whole-home comfort, the Rinnai Multi Split Ducted Air Conditioner provides flexible multi-room climate control from a single outdoor unit.

Specifications

Dimensions

Net

245 x 1000 x 750 mm Height x Width x Depth

Dimensions

Gross

304 x 1225 x 860 mm Height x Width x Depth

Weight

31.5 / 36.9 kg Net / Gross

Rated Capacity

7.3 / 8.0 kW Cooling / Heating

Operating Range

16 ~ 32 / 0 ~ 30 °C Cooling / Heating

Airflow

Turbo / Hi / Med / Lo / Silence

472 / 417 / 361 / 278 / 194 L / s

Indoor Noise Level Turbo @ 1.5m

Turbo / Hi / Med / Lo / Silence

41 / 38 / 36 / 33 / 28 dB(A)

Dimensions

Net

245 x 1000 x 750 mm Height x Width x Depth

Dimensions

Gross

304 x 1225 x 860 mm Height x Width x Depth

Weight

31.5 / 36.9 kg Net / Gross

Rated Capacity

7.3 / 8.0 kW Cooling / Heating

Operating Range

16 ~ 32 / 0 ~ 30 °C Cooling / Heating

Airflow

Turbo / Hi / Med / Lo / Silence

472 / 417 / 361 / 278 / 194 L / s

Indoor Noise Level Turbo @ 1.5m

Turbo / Hi / Med / Lo / Silence

41 / 38 / 36 / 33 / 28 dB(A)

Resources

Brochure

Multi-Split Air Conditioner Brochure

Download
Operation-Manual

Multi-Split Air Conditioner Operation Manual

Download
Operation-Manual

Ducted Air Conditioner R32 Operation Manual

Download
Operation-Manual

Ducted Air Conditioner R32 Wired Remote Controller Operation and Installation Manual

Download
Other

Multi-Split Air Conditioner Combination Tables

Download
Installation-Manual

Multi-Split Air Conditioner Outdoor Unit Installation Manual

Download
Installation-Manual

Ducted Air Conditioner R32 Installation Manual

Download
Warranty

Air Conditioner Warranty Booklet

Download

FAQs

Browse helpful answers to common product questions, with guidance on what to consider when choosing the right option.

Benefits

  • Allows multiple indoor units to connect to a single outdoor unit

  • Provides individual temperature control in different rooms

  • Saves outdoor space compared to installing multiple split systems

  • Offers both heating and cooling in one system

  • Energy efficient when only conditioning occupied rooms

Considerations

  • Higher upfront cost than a single split system

  • Installation is more complex and requires professional design and installation

  • Indoor unit capacity is limited by the connected outdoor unit

  • If the outdoor unit requires servicing, multiple rooms may be affected

  • Best suited to homes requiring climate control in several rooms

Disclaimer / Footnotes

Product codes:
Outdoor: 5 - MON5H11B1LA / MON5H14B1LA | 6 - MON6H19B1TA
Indoor Ducted: DINLR07B1A
